Centering Ring, Standard, NW50, DN50KF, FKM Elastomer, Aluminum, (EU/Metric PN: 7710016)

Features

• Standard ring mates two ISO KF Kwik-Flanges™ of equal size
• Includes elastomer gasket
• Aluminum construction Vacuum rated to 1x10-8 Torr
• Europe and Metric Catalog Equivalent Part Number: 7710016

Specifications

Material                                             

• Ring                      Aluminum
• Gaskets                  Fluorocarbon-based fluoroelastomer (FKM / FPM) Elastomer Gasket

Vacuum Range                  Vacuum rated to 1x10-8 Torr

Temperature Range          Bakeable to 200°C ; Sustained use to 150°C

Weight                              0.4lb to 1lb  or 0.2kg to 0.5kg maximum
