Flange, 4.58" x 2.5", Tapped, 304ss

Part Number / SKU
130023
$113.40
Availability: Backordered

This product is currently on back order. Orders are still accepted, but the requested qty will be back ordered.

Quantity:
0 Available
Lead Time:
6 weeks
Have a Question? Our customer service team is ready to help! Monday - Friday 9am - 6pm PST Call 1.510.265.3500 or Email Us.
Flange, 4.58" x 2.5", Tapped, 304ss
130023_fr_dwg (4.25 kB)
130023_sc_dxf (3.02 kB)
130023.stp (149.80 kB)
130023_fr_dxf (2.37 kB)
130023_sc_dwg (4.84 kB)

More Information

Specifications

Specifications
Weight (lb) 2.500000
Material 304SS (1.4301 | UNS S30400) Stainless Steel
Number of Bolt Holes 10
Thread Size 0.312-24 UNF
Bolt Hole Type Tapped
Flange Geometry Non-Rotatable
Flange Size DN75CF 117mm | 4.625 " (4 5/8")
Flange Type Del-Seal CF ConFlat
Internal Diameter (ID) 2-1/2 Inch Nominal (2.375)
